Medical Refrigerator-Single Door

Model

BXC-V50M (F/G)

BXC-V70M(F/G)

BXC-V95M (F/G)

BXC-V130M (F/G)

BXC-V105M(F/G)

External Size(W*D*H) mm

450*445*575

445*470*700

445*470*900

510*515*900

505*525*925

Internal Size(W*D*H) mm

382*359*415

400*347*528

400*347*708

419*395*738

385*356*737

Capacity

50L

70L

95L

130L

105L

Temperature Range

2℃～8℃

Temperature Accuracy

0.1℃

Control System

Microprocessor Control , Large Screen LED Display

Alarm

Audible and Visual alarm-Standard:High and low Temperature Alarm,

Sensor Failure Audible and Visual Alarm-Optional: Power Failure,Door Ajar

Four Alarmsleft areall standard）

Refrigeration Type

Forced air refrigeration system

Refrigerant

R134a/R600a, CFC Free

Condenser&Evaporator

High efficiency air-cooled condenser, made of copper

Defrost

Auto defrost  Removing

Decondensation

Manual

Door

Foam/Glass

Construction

Structure

Unibody design & Mono-assembly foaming ( Rigid polyurethane insulation material)

Internal Material

HIPS blister tank

External

Material

Cold-rolled steel coated with anti-bacteria powder coating

Baskets

1 pc

2 pcs

3 pcs

3 pcs

3 pcs

Consumption

60W

70W

70W

90W

78W

Power Supply

AC220V±10%, 50/60Hz

Optional

Auto decondensation, Lock of door

Gross Weight(Kg)

26kg(F)/

30kg(G)

43kg(F)/

48kg(G)

53kg(F)/

58kg(G)

53kg(F)/

58kg(G)

55kg(F)/

55kg(G)

Package Size(W*D*H) mm

565*575*660mm

575*590*775mm

575*590*995mm

620*645*975mm

520*540*940
